Accelerated UV Aging Testing Chamber At Wavelength 280~400nm

  • Model Number:

    OLT-UV-260
  • Compliance:

    CE Certified
  • Minimum Order Quantity:

    1
  • Voltage:

    108V-380V 50HZ
  • Dimension(L*W*H):

    680*1300*1500mm
  • Packaging Details:

    Standard export wooden box
  • Delivery Time:

    8-10 day
  • Product Details

Standard Features of Accelerated UV Aging Testing Chamber

♦ Fluorescent UV lamps (8) - 40 W
♦ Black Panel Temperature (BPT) at controlled, BPT 30~70℃
♦ Temperature from Ambient to 90℃
♦ Spraying water, automatic water supply
♦ Water reservoir 50 Liter
♦ Can hold 48 pieces of specimens
♦ Programmable color display touch screen controller
♦ Safety protection system
♦ Easy to mount samples on the holders
♦ CE and RoHS compliance


Model

OLT-UV-260

OLT-UV-SI-260

Internal dimensions (mm)

450*1170*500

450*1170*500

Overall dimensions (mm)

680*1300*1500

680*1300*1500

Capacity of test specimens

       48 pieces Individual specimen size is 75mm * 150mm

48 pieces Individual specimen size is 75mm *150mm

Controller

Programmable color display touch screen controller

Programmable color display touch screen controller

Temperature range

Ambient~90℃ ±2℃

Ambient~90℃ ±2℃

Humidity range

≥95%R.H ±2%R.H

≥95%R.H ±2%R.H

Black Panel Temperature

BPT  30~80℃

BPT  30~80℃

Irradiation Source

Fluorescent UV lamps (8) - 40 W

Fluorescent UV lamps (8) - 40 W

UV wavelength

290 ~ 400nm

290 ~ 400nm

Irradiance Control

N/A

0.3 ~ 20 W/m2(340 nm / 313 nm)

Water Spray

Spraying water

Spraying water

Distance of Specimen and lamp

50mm

50mm

Nominal power

5000W

5500W

Power Supply

108V-380V 50HZ

108V-380V 50HZ

Accelerated UV Aging Testing Chamber is equipped with fluorescent UV lamp which can simulate the UV spectra of sunlight, exposes materials to alternating cycles of UV light, moisture and temperature at controlled. It simulates dew and rain with condensing humidity and/or water spray.





Pre-Sales Service

Inquiry and consulting support.

Offering quotation and specifications.

Provide test solutions.

Visiting our factory.

Standard and custom

After-Sales Service

3 Years Warranty, Lifelong Follow-up Services.

Training how to install and operate the machine.

Training how to maintain the machine.

Response within 24 hours once got questions from customers.

Send spare parts within 2 days after got notice.

Engineers available to service machines overseas to install and commissioning.

Installation instructions
Operation manual and video available for installation & operation


Package with export standard wooden box, It can be used for sea, air, railway, truck transportation.
