Laboratory ring pulverizer small ring pulverizer with continuously feeding

Laboratory ring pulverizer small ring pulverizer

  • Product Orgin:

    China

  • Shipping Port:

    Xiamen/Shanghai

  • Warranty:

    1 Year

  • Dimension(L*W*H):

    550x570x835mm

  • Weight:

    115-300kg
  • Product Details

Product Application for laboratory grinding mill machine Sealed sample pulverizer


Sealed sample pulverizer is a small lab grinding machine for grinding the ore/material samples into powder, which has been widely used in the laboratory of the geology, mining, metallurgy, coal, power, chemistry and building industries, for the none pollution sample testing.

Sealed sample pulverizer gets an "automatic dust proof" and a "pot anti-loose" device, which provide the machine advantages of low noise, no dust, and easy operation.

Sealed sample pulverizeradapt high frequency vibrating grinding method to make the power fine and event, no need screening and shrinking, prevent sample mixing.

model
feeding size(mm)
weight of charge(g)
discharge granularity(mesh)
grinding time(min)
motor power(kw)
total weight(kg)
overall size(mm)
GJ-I
<12
100
120-200
1-3
1.1
145
640*560*730
GJ-II
<25
200(400)
120-200
1-3
1.1
225
800*740*910
GJ-AX
<12
700
120-200
2-5
1.1
300
800*740*910
GJ500-1
<25
500
120-200
1-3
1.1
280
800*740*910
GJ-IA(MZ-100)
<12
100
100-200
1-3
1.1
115
550*540*750
2MZ-100
<12
2*100
100-200
2-4
1.1
150
530*530*800
3MZ-100
<12
3*100
100-200
2-4
1.1
160
530*530*800
4MZ-100
<12
4*100
100-200
2-5
1.5
260
740*740*950
5MZ-100
<12
5*100
100-200
2-5
1.5
270
740*740*950
6MZ-100
<12
6*100
100-200
2-5
1.5
280
740*740*950
7MZ-100
<12
7*100
100-200
2-5
1.1
300
740*740*910
1MZ-200
<20
200
100-200
2-4
1.1
150
530*530*800
1MZ-400
<25
400
100-200
2-5
1.1
280
740*740*910
MZ-1000
<12
1000
100-200
2-5
1.1
239
740*740*910
2MZ-200
<20
2*200
100-200
2-5
1.5
257
740*740*950
2MZ-400
<25
2*400
100-200
2-5
1.5
257
740*740*950
3MZ-200
<20
3*200
100-200
2-5
1.5
265
740*740*950
3MZ-400
<20
3*400
100-200
2-5
1.5
280
740*740*950
4MZ-400
<20
4*400
100-200
2-5
1.5
278
740*740*950
4MZ-200
<20
4*200
100-200
2-5
1.5
278
740*740*950
LMZ-120
<12
continuous loading unloading
120-320
2-5
1.1
160
520*52

Main Features for laboratory grinding mill machine Sealed sample pulverizer

1. High efficient no need screening again, the output material could be used for testing directly.
2. Digital timing screen, special designed high quality motor, with long service life.
3. With shock-absorbing stand.
4. Sealed grinding pot, dust proof, no pollution.
5. Low noise, smooth operating, complete sealed machine, with high safety operation standard.
6. High standard sealing design, no leaking for dry or wet method grinding.
7. Reliable, evenly output size, short grinding time.
8. Simple and reasonable structure, good out look, easy to operate, maintenance, and clean
