Item NO.:
GY-23GS-400LProduct Orgin:
ChinaShipping Port:
XiamenPayment:
T/TModel Number:
GY-23GS-400L or customizeMinimum Order Quantity:
1Voltage:
220/240/380 Volt 50/60 HzPower:
3kw-5kwWarranty:
1 Year
● Provide a touch screen and PLC control system,also can be the indicators testing record function;
● External or internal LED light source controlled lighting time light intensity, change the light color;
● Cooperate with cleaning device, through the pump drive cleaning ball to the glass wall and tube;
● Optional constant temperature system,configuration refrigeration equipment, hot and cold temperature range 20-40 ℃ can be set up;
● Equipped with low shear force algae water pump, is not easy to damage the algae;
● With frequency conversion control system,the flow can be adjusted;
● Have good reliable leak prevention and removable structure;
● Can according to customer's different farming algae bioreactor design different tube light structure.
◆ Container body：tube outside diameter of 60 mm，Structure of aluminum alloy bracket and PVC pipe clamp.
◆ Material: High borosilicate glass tube, PMMA tank
◆ External dimensions: L5 * W1.5 * H2.5 (m)
◆ Total capacity： 400L
◆ LED light source: full spectrum light source, DC24V, 0-13000 (lux)
◆ Air pump: voltage AC220V, gas flow rate 100L/min(mandatory)
◆ Water pump: voltage 380V, 2.2kw, water flow 5T-10T/h
◆ Detection accuracy: Temperature ± 0.3 ℃,pH±0.03
◆ Measurement range: PH (1-14)
◆ Voltage: 380V, 3kw-5kw (reference)
◆ Optional: PLC control, touch screen, and other sensor modules.
Main components of a photobioreactor:
1. Light source system: Usually uses LED lights or fluorescent lamps, and the intensity and wavelength of light can be adjusted to meet the needs of different photosynthetic organisms.
2. Reactor container: A container containing culture medium and photosynthetic organisms, usually made of transparent or translucent materials so that light can fully penetrate.
3. Gas supply system: Provides gases such as carbon dioxide to promote photosynthesis and growth.
4. Stirring and circulation system: Ensures uniform distribution of nutrients and light through stirring or circulating flow.
5. Temperature control: Some photobioreactors are equipped with temperature control systems to maintain a suitable growth environment.
Application areas:
1. Algae cultivation: Production of biofuels, food additives, pharmaceuticals, cosmetics, etc.
2. Water treatment: Use algae or other photosynthetic microorganisms to purify pollutants in wastewater.
3. Biofuel production: Use algae photosynthesis for oil synthesis for biodiesel production.
4. Environmental remediation: Removing carbon dioxide or other harmful substances from the atmosphere through photosynthesis.
