Lead Time:
1-7 daysProduct Orgin:
ChinaShipping Port:
XiamenModel Number:
OLT-PM-M51Power:
AC 220±22V 50Hz 35AWarranty:
1 year
The Ollital 300℃/0.8MPa Lab Melt Spinning Machine is a specialized pneumatic-driven melt electrospinning system designed for the fabrication of micro and nanofibers without the use of organic solvents. By heating polymers to their molten state (up to 300°C) and applying pneumatic pressure (up to 0.8MPa) to extrude the melt through a spinneret, this machine produces fibers via electrostatic drawing or direct melt blowing. It is ideal for processing thermoplastic polymers that are difficult to dissolve or require solvent-free processing, such as polypropylene (PP), polyethylene (PE), polyamide (PA), polylactic acid (PLA), and polyurethane (TPU). This system is widely used in tissue engineering, filtration, biomedical textiles, and green manufacturing research.
Primary Applications:
Biomedical Textiles: Solvent-free scaffolds for cell culture and wound dressings
Filtration Membranes: Melt-blown nonwovens for air/water filtration
Drug Delivery Systems: Thermoplastic polymer fibers for controlled release
Green Manufacturing: Eliminating solvent waste and toxicity
Polymer R&D: High-temperature rheology and spinnability testing
3D Fiber Deposition: Additive manufacturing with molten polymers
Common polymers include: PP (polypropylene), PE (polyethylene), PLA (polylactic acid), PCL (polycaprolactone), PA (nylon), TPU (thermoplastic polyurethane), PEEK (polyether ether ketone – requires 400°C option), and many other thermoplastics with melting points below 300°C.
|
Product name
|
Selection of experimental electrospinning machine
|
Production model
|
||
|
Equipment model
|
OLTPM-M51
|
OLTPM-M52
|
OLTPM-M53
|
OLTPM-M54
|
|
Product positioning
|
Portable principle type
|
Standard test type
|
Full-function scientific research type
|
Production machine
|
|
Power supply
|
AC220V
|
AC380V
|
||
|
Maximum power (KW)
|
≤6
|
20-100
|
||
|
Dimensions (CM)
|
/
|
60*80*170
|
100*100*180
|
160*300*180
|
|
Loading method
|
Single syringe with gap
|
Two syringes with gap
|
Two injection systems
|
Continuous feed
|
|
Loading amount
|
1-10mL
|
(1-30mL)
|
(1 -30mL)*(1-12)
|
Continuous feed
|
|
Material heating
|
/
|
Optional
|
Optional
|
Optional
|
|
Spinneret
|
Detachable single needle
|
Detachable single to multiple needles, coaxial spinning
|
No Needle
|
|
|
Spinneret movement
|
Fixed
|
Reciprocating
|
Lifting + Reciprocating
|
Rotating
|
|
Raw material flow
|
0.1-20ml/h
|
0.1-50ml/min
|
100-1000ml/min
|
|
|
High voltage power supply
|
+30KV
|
+30KV
|
-30KV~+50KV
|
-30KV~+100KV
High power power pack
|
|
Collection unit
|
Roller + flat plate
|
Roller + flat plate
(roller optional)
|
Full series
|
Wide collection belt
|
|
Drum collector (CM)
|
D10*21 roller
|
D10*21 roller
|
Multiple specifications of rollers
|
/
|
|
Collection drum speed
|
50-1000r/min
|
50-1000r/min
|
50-2800r/min
|
|
|
Collection distance
|
5-30cm(Manual)
|
5-30cm(Manual)
|
5-30cm(Automatic)
|
5-30cm(Manual)
|
|
Plate movement
|
/
|
/
|
X/Y Scan
|
/
|
|
Fiber diameter
|
100nm-200nm
|
50nm-200nm
|
10nm-200nm
|
10nm-200nm
|
|
Environmental control
|
/
|
Optional temperature and humidity control
|
Temperature and humidity control
|
Clean space with temperature and humidity control
|
|
Control method
|
Decentralized independent control
|
Touch interface
|
Programmable touch interface
|
Programmable touch interface
|
|
Optional consumables
|
/
|
Needle
|
Nozzle/Collector
|
/
|
|
Optional accessories
|
/
|
Temperature and humidity control/nozzle/collector
|
/
|
|
Ollital Technology would like to establish win-win business cooperation with distributors all over the world.
Multi-functional Laboratory Electrostatic Spinning Machine is an advanced benchtop system designed for the fabrication of micro and nanofibers via electrospinning technology.
Standard Test Electrostatic Spinning Machine is a compact, reliable, and easy-to-use electrospinning system designed for routine nanofiber fabrication in research and quality control laboratories.
Pilot Production Dry/Wet Spinning Machine is a precision-engineered pilot-scale solution spinning system designed for the production of high-quality fibers via both dry spinning and wet spinning methods.
M42 Double-Layer Wet Spinning Experimental Machine is a compact, bench-top wet spinning system specifically designed for laboratory-scale production of double-layer (core-sheath) fibers and advanced hollow fiber membranes.
