Product Description
The 30ml Chemical Glass-Lined Reactor Liquid Phase Photochemical Reactor is a compact, high-performance reactor system designed for liquid-phase photochemical reactions in laboratory environments. It combines excellent chemical resistance, precise temperature control, and stable light irradiation, making it ideal for studying organic synthesis, photocatalysis, and advanced material preparation.
The 30 mL glass-lined chamber provides a chemically inert and corrosion-resistant environment, ensuring reliable results even with strong acids, alkalis, or organic solvents. The reactor can be equipped with UV or visible light sources and supports continuous or batch operation, offering flexibility for a wide range of research applications.
Key Features
High-Quality Glass-Lined Chamber
Excellent corrosion resistance against strong acids and solvents.
Smooth inner surface prevents contamination and ensures easy cleaning.
30 mL Reaction Volume
Perfect for small-scale or parallel experiments.
Suitable for reaction screening, process development, and catalyst testing.
Liquid Phase Photochemical Design
Supports visible or UV light sources for various photochemical reactions.
Uniform light distribution ensures consistent reaction efficiency.
Precise Temperature Control
Integrated heating/cooling jacket maintains stable reaction conditions.
Temperature range typically up to 120°C (customizable).
Efficient Stirring System
Magnetic or mechanical stirring for uniform mixing.
Ensures homogeneous reactant distribution in the liquid phase.
Optional Light Source Configurations
UV lamps, LED modules, or fiber optic light guides available.
Adjustable wavelength and intensity for different research needs.
Technical Specifications (Customizable)
Reaction Volume: 30 mL
Material: Glass-lined stainless steel or quartz reactor tube
Temperature Range: Room temperature to 120°C (optional higher range)
Pressure Range: Up to 1 MPa (custom design available)
Light Source: UV / Visible / LED (custom wavelength available)
Stirring Type: Magnetic or mechanical stirring
Control System: Digital temperature controller and timer
Cooling Method: Circulating water or air cooling
Applications
Photochemical synthesis and photocatalysis
Organic synthesis and oxidation/reduction studies
Catalyst screening and mechanism research
Fine chemicals, pharmaceutical, and material R&D
Environmental chemistry and degradation studies
Advantages
Chemically inert and corrosion-resistant glass-lined chamber
Compact 30 mL design ideal for laboratory-scale research
Uniform and efficient light exposure for reproducible results
Flexible configuration with customizable light sources
Safe, reliable, and easy-to-clean design for long-term use
Optional Configurations
Multiple reaction cells for parallel experiments (e.g., 4–8 parallel tests)
Different light source options (UV, visible, LED)
Data recording and export interface
Temperature and light intensity sensors
Automated control system for precise process regulation
1.Pure solid phase photochemical reactor,support customized various sizes depending on your needs.
2.Low temperature apparatus is available.
Small-Volume Reaction Unit
| Parameter | Specification |
|---|---|
| Quartz Tube Volume | 30 mL, 50 mL (customizable) |
| Number of Samples | Up to 8 samples simultaneously (customizable) |
| Magnetic Stirring | Digital 8-position magnetic stirrer, synchronized speed adjustment for 8 samples |
OLT-GHX-V Standard Configuration
| Component | Quantity |
|---|---|
| OLT Digital Photochemical Controller (voltage, current, power display, temperature protection) | 1 |
| Dedicated Photochemical Water Bath | 1 |
| Photochemical Reaction Dark Box | 1 |
| Double-Layer Quartz Cold Trap | 1 |
| Mercury Lamp 1000 W | 1 |
| Xenon Lamp 1000 W | 1 |
| Metal Halide Lamp 500 W | 1 |
| Digital 8-Position Magnetic Stirrer | 1 |
| Quartz Tubes (30 mL ×8, 50 mL ×8) | 16 |
| UV Protection Glasses | 1 |
| Movable Trolley | 1 |
Applications
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
