Model Number:
OLT-IICompliance:
CEMinimum Order Quantity:
1Capacity:
200-5000mlVoltage:
108V-240V 50/60HZWarranty:
1 yearPackaging Details:
Export wooden packageDelivery Time:
6-8 dayMicro Algae Cultivation Photobioreactor – Outside-illuminated Photoreactor
Product Overview
The Micro Algae Cultivation Photobioreactor is an advanced laboratory and pilot-scale photoreactor designed for efficient microalgae growth and cultivation under controlled light, temperature, and nutrient conditions. Its outside-illumination design ensures uniform light distribution across the culture medium, optimizing photosynthetic efficiency and biomass productivity.
This photobioreactor is ideal for research in biotechnology, biofuel production, environmental remediation, and nutraceutical applications. It provides precise control over environmental parameters to support consistent, reproducible results.
Key Features
Technical Specifications
| Parameter | Specification |
|---|---|
| Culture Volume | 1–50 L (customizable) |
| Illumination Type | Outside-illuminated LED or Xenon light source |
| Light Intensity | Adjustable, uniform distribution |
| Temperature Range | 15–40°C (thermostatic control) |
| Mixing | Magnetic stirrer or optional mechanical stirrer |
| CO₂ Supply | Optional gas inlet for aeration and CO₂ enrichment |
| Number of Cultures | 1–8 parallel cultures (customizable) |
| Optical Material | Transparent glass or acrylic with high light transmittance |
Standard Configuration
| Component | Quantity |
|---|---|
| Outside-illuminated Photobioreactor Chamber | 1 |
| Digital Control Panel (temperature, light, stirring) | 1 |
| Magnetic Stirrer or Mechanical Stirrer | 1 |
| LED or Xenon Light Source | 1 |
| Culture Tubes or Vessels | 8 (customizable) |
| Cooling/Heating Module | 1 |
| Gas Supply Inlet (CO₂/air) | 1 |
| Movable Trolley | 1 |
Applications
Advantages
|
Name
|
Xenon light source
|
Main features：
|
|
model
|
OLT-GHX-XE-300
|
Transmission-reflection filter (visible high reflection) original PE300W xenon lamp. Equipped with lifting device. The control chassis has an external interface for optical feedback, and an optical feedback circuit can be added to increase the stability of the light. |
|
Bulb power
|
300W (can be customized)
|
|
|
Power adjustment range
|
100~300W continuously adjustable
|
|
|
Bulb life
|
Not less than 1500H (full power operation)
|
|
|
electric current
|
8-22A adjustable
|
|
|
total optical power
|
50W
|
|
|
Heat dissipation form
|
High temperature resistant metal fan + metal heat dissipation module
|
|
|
Light collection form
|
Ellipsoid total reflection
|
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
