Lead Time:
3-5Product Orgin:
ChinaShipping Port:
XiamenPower:
380V/220V 50Hz 3.6kwDimension(L*W*H):
2300*560*1410Weight:
800
Product Description
Applicable Material: 1.PVC,PET,PS; 2.Aluminum foil (PTP), Aluminum plastic composite film, paper-plastic composite film, etc.
Basic Procedure: 1. Material unfolding and conveying 2, preheating 3, Air blow forming 4, filling 5, Heat-sealing 6, perforation, batch number 7, traction 8, punching output 9, waste recycle
Feeding Type: Special feeder (liquid, sauce, paste, cream type) is customized according to material properties.
Main Users: Focus on the coastal areas of Guangdong Province, Shanghai, Ningbo, Yiwu Yangtze River Delta and export to Singapore, Italy, Brazil, Malaysia, Indonesia, Taiwan, Hong Kong, the United States, Russia, Canada, Australia and other countries and regions. The market share of products has reached over 90% in China.
Product Parameter
| Cutting Frequency(Times/min) |
6-20 |
|
Max. Forming area and depth (mm) |
140*110*14 |
|
Stroke (mm) |
40-120 (can be designed as customers requirements) |
|
Standard Plate(mm) |
80*57 (can be designed as customers requirements) |
|
Air Pressure(Mpa) |
0.4-0.6 |
|
Air supply |
≥0.2 m³/min |
|
Total Power |
380V/220V 50Hz 3.6kw |
|
Main Motor Power (kw) |
1.1 |
|
PVC Hard Pieces(mm) |
0.15-0.5*150 |
|
PTP Aluminum Foil(mm) |
0.02-0.035*150 |
|
Dialysis Paper(mm) |
50-100g*150 |
|
Mould Cooling |
tap water or recycling water |
|
Overall Dimensions(mm) |
2300*560*1410(L*W*H) |
|
Weight (kg) |
800 |
Packing
