Lead Time:
3-5 daysModel Number:
OLT-TH-150Minimum Order Quantity:
1Operation method:
PLCMixing method:
Touch ScreenCapacity:
150LTemperature range:
-20~150℃Packaging Details:
Stand export wooden package
| Model | OLT-TH-80 | OLT-TH-150 | OLT-TH-225 | OLT-TH-408 | OLT-TH-800 | OLT-TH-1000 |
|---|---|---|---|---|---|---|
| Inner Chamber Size W*H*D(cm) | 40*50*40 | 50*60*50 | 60*75*50 | 80*85*60 | 100*100*80 | 100*100*100 |
| External Chamber Size W*H*D(cm) | 90*142*100 | 100*152*113 | 110*167*113 | 130*177*123 | 150*192*144 | 150*192*163 |
| Inner Chamber Volume(L) | 80 | 150 | 225 | 408 | 800 | 1000 |
| Temperature Range | -70°C~+150°C(180°C)(A:-20℃ B:-40℃ C:-60°℃ D:-70℃) (Optional) | |||||
| Humidity Range | N/A | |||||
|
Humidity range
|
20% ~ 98% RH | ||||
|
Temperature fluctuations
|
± 0.5 ℃ | ||||
|
Temperature deviation
|
± 2.0 ℃ | ||||
|
Humidity deviation
|
± 2.5% RH | ||||
|
Heating rate
|
3 ℃ / min | ||||
|
Cooling rate
|
1 ℃ / min | ||||
|
Cooling system
|
Mechanical compression refrigeration system | ||||
|
Humidifier
|
External isolation, stainless steel surface evaporation humidifier | ||||
|
Air circulation
|
Centrifugal wind fan | ||||
|
Exterior material
|
Steel Plate with protective coating | ||||
|
Interior material
|
SUS304 stainless steel | ||||
|
NO.1 Characteristics
1.Cold and hot impact testing machine mini temperature humidity test chamber Evaporator no frosting under longtime Low temperature and low humidity running. |
|
NO.2 Application Field Cold and hot impact testing machine mini temperature humidity test chamber simulating product under the condition of temperature and humidity combination (high and low temperature operation & storage, temperature cycle, high temperature and high humidity, low temperature and humidity and condensation test, etc.), check whether the adaptability and characteristics of the product itself have changed. |
