Digital Touch Screen Differential Scanning Calorimeter

Widescreen touch structure of industrial level, rich display information, including the set temperature, sample temperature, oxygen flow rate.
  • Item NO.:

    LIYI
  • Lead Time:

    7days
  • Shipping Port:

    XiaMen
  • Product Details

Application

     DSC is designed to determine the inner heat transition relating to temperature and heat flow, it is widely used in the field of polymer development, performance testing & quality control. DSC research and development includes the following field: glass transition temperature, melting point, cold crystallization, crystallization, phase transition, oxidation induction time (OIT).



Technical features:

     1. Widescreen touch structure of industrial level, rich display information, including the set temperature, sample temperature, oxygen flow rate.

     2. Nitrogen flow, differential thermal signals, all kinds of switch state, flow goes to zero.

     3. USB communication interface, generality is strong, reliable communication don't interrupt, support the restore connection function.

     4. Standard standard samples, convenient customer constant temperature correction coefficient. Software adaptive resolution of computer screens, each software automatically according to the computer screen size to adjust the curve display mode. Support for notebook, desktop; Support the Win2000, XP, VISTA, Windows 7 operating system, etc.

     5. Improved installation process, all adopt the machinery fixed way, completely to avoid contamination of furnace inside colloid to differential thermal signal.


Specification

Items
Parameters
Temperature range
Room temperature to 500 °C
The temperature resolution
0.1 °C
Heating rate
0.1 ~ 80 °C / min
DSC range
0 ~ + 200 mw
DSC resolution
0.01 mW
DSC sensitivity
0.1 mW
Aluminum box size
41 cm * 30 cm * 53 cm
Product Effects
