Model Number:
OLT-X75Compliance:
CE CertifiedMinimum Order Quantity:
1Voltage:
108V-240V 50/60HZWarranty:
1 yearPackaging Details:
Export wooden packageDelivery Time:
2-5 days1. Short arc xenon lamp light sources are the preferred artificial sources to simulate sunlight. The high color
temperature(6000K) of the Xenon lamps is a close match to the solar temperature. This results in very
similar solar spectra in the UV and VIS although the source has some Xe emissions lines in the near IR.
2. Application for fluorescence, Luminescence and Phosphorescence, Absorbance and Reflectance,
Photochemistry, Photolithography, Detection of optical Schlieren, Solar simulation.
3. A spherical reflector collects the output from the rear of the lamp and focuses it on or near the arc, for
collection by the condenser.The output is increased by as much as 60 %.
| Lamp Power | 300 W | Power Adjustment Range | 100–300 W, continuously adjustable |
| Lamp Life | ≥1500 h (full power) | Current | 8–22 A, adjustable |
| Total Light Power | 50 W | Parallel Beam Spot Diameter | 30–62 mm (depending on irradiation distance) |
| Parallel Beam Divergence Angle | Avg. 6° | Cooling Method | High-temperature resistant metal fan + metal heat dissipation module |
| Light Collection Method | Ellipsoidal total reflection | Optical Window Diameter | 24.0 mm (circular) |
| Working Spot Diameter | 30–62 mm (circular) | Light Output Form | Horizontal, vertical, or any angle (rotatable along optical axis, 45° incidence then vertical downward, can also be horizontal) |
| Infrared Transmission | ≥80%, wavelength range 800–1100 nm | Visible Reflection | ≥95%, wavelength range 350–780 nm |
| Filter Mounting Device | Yes, diameter 58 mm | Standard Configuration | 300 W xenon lamp power supply, cooling module, rotation head, filter device, one transmissive-reflective filter (high-reflective visible), one UV filter, one visible light filter, stainless steel lifting platform |
Lamp adjustment：
1. The housing has precise external lamp adjusters.They let you place the arc where you want it.
2. This is important for simplifying fiber and slit illumination. In many applications, this eliminates the need
for adjust any optics located beam path outside the housing.
Main features of short arc xenon light source:
1.Spectral range from UV to VIS(200-2500nm).
2.Optical axis height is 157-193mm.
3.Output beam diameter is 46mm.
4.Supports wide range of accessories.
5. Fan cooled housing.
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
