High quality 1.5L scale lab spray dryer equipment
Lab scale spray dryer is suitable for the production of in universities, research institutes and food and pharmaceutical chemical enterprises.
In many product development processes, a key challenge for R&D personnel is how to thoroughly blend raw materials with differing properties to ach
In industries such as painting, printing, electronics, and automotive parts manufacturing, organic solvents are widely used in cleaning, thinning, deg
As the printing industry continues to evolve toward higher quality, greater efficiency, and environmental sustainability, the consumption of organic s
A closer look at how heating methods influence equipment design, installation requirements, and drying performance When reviewing spray dryer quotatio
Model Number:
OLT-FDJ-40Compliance:
CE CertifiedMinimum Order Quantity:
1Voltage:
108V-380V 50/60HZWarranty:
3 yearPackaging Details:
Export wooden packageDelivery Time:
6-8 Day
| Freeze-dried area | OLT-FDJ-2 | OLT-FDJ-3 | OLT-FDJ-5 | OLT-FDJ-10 | OLT-FDJ-13 | OLT-FDJ-15 | OLT-FDJ-20 | OLT-FDJ-25 | OLT-FDJ-30 | OLT-FDJ-40 |
| Shelf area | 2.16 | 3.2 | 5.4 | 10.2 | 20.96 | 40.4 | 90.7 | 24.59 | 29.6 | 41.86 |
| Cold trap water capture | 30 | 50 | 100 | 200 | 250 | 300 | 400 | 500 | 600 | 800 |
| Vial bottle (22mm) of Xilin | 4000 | 6000 | 11400 | 22000 | 29400 | 32700 | 4480 | 55800 | 67200 | 95100 |
| Vial bottle (16mm) of Xilin | 800 | 20000 | 21500 | 41900 | 55600 | 61800 | 84700 | 105600 | 102700 | 179000 |
| Shelf length (mm) | 900 | 850 | 1020 | 1250 | 1200 | 1200 | 1495 | 1495 | 1800 | 2000 |
| Shelf width (mm) | 500 | 600 | 900 | 900 | 1200 | 1200 | 1200 | 1495 | 1495 | 1495 |
| Shelf Number | 5+1 | 6+1 | 5+1 | 9+1 | 9+1 | 10+1 | 11+1 | 11+1 | 11+1 | 14+1 |
| Whole machine size (mm) | 3600 | 3900 | 4500 | 5200 | 6500 | 6500 | 7300 | 7300 | 7600 | 8000 |
| Whole machine size (mm) | 1750 | 2200 | 2300 | 2200 | 2300 | 2300 | 3000 | 3000 | 3000 | 3200 |
| Full machine size (mm) | 2850 | 3100 | 3100 | 3800 | 3900 | 3900 | 4200 | 4200 | 4200 | 4600 |
| Rough weight (ton) | 3 | 4.5 | 7 | 10 | 12.5 | 13 | 17.5 | 20 | 25 | 30 |
Baffle heating system:
By controlling the temperature generated by heating the diaphragm, the uniformity of temperature is more accurate and the freeze-drying speed is increased.
Sample prefreeze system:
The freezer has a refrigeration system under the tray, which can pre freeze the samples before freezing.
Cold well defrosting system:
After the freeze drying, the cold trap is defrosting quickly to shorten the next freeze-drying time.
Safety cap system:
Under the vacuum condition, the sealing gland system adopts an oil cylinder to achieve a safe and precise sealing function.
Freeze-drying curve recording function:
Curve data recording system, USB interface data memory can store data in the computer and realize printing.
Remote control system (selection):
Ethernet is connected with computer remote control to record freeze-drying parameters and monitor and control freeze drying process.
